Structural Steel Detailing Services for US, Canada and Australia

Steel Detailing Support Built for Fabricators
Fast, accurate detailing that keeps your shop moving and prevents costly rework.

Get a Quote in 24 Hours


Request a quote
24-Hour Workflow Advantage for U.S. & Canadian Fabricators
Because we operate from Sri Lanka, your late-day markups can be processed while your team is offline and returned by the next North American business morning.

This allows:
  • Faster drawings revision
  • Reduced project delays
  • Continuous detailing workflow
  • Better coordination between engineering and fabrication
About Us
SteelTek Detailing provides high precision structural and miscellaneous steel detailing for fabricators, contractors, and engineers.
We specialize in producing exact 3D Tekla models to ensure every element matches perfectly before it hits the shop floor, preventing costly field rework.
By leveraging custom API automation, we generate full workshop drawings and erection drawings 30% faster than industry standards while maintaining compliance with building codes.

Our comprehensive data packages support your entire workflow, providing material lists, part lists, shipping bills, bolt lists, and CNC-ready files (NC/DXF) to streamline fabrication and site logistics. With experience managing 100+ ton steel projects for global brands like Hilton and Audi, your project will be handled with technical care and professional expertise.

Need reliable steel detailing for your project?
Contact our Tekla detailing team today.
Contact Us

Services

General Arrangement

Comprehensive AB plans, Plan views, Elevation views and typical connection details

Shop Drawings

High quality fabrication Assembly and single part drawings issued to fabricator

DXF and NC files

All part drawings converted to DXF and NC files for CNC machines

Advanced BOM and other reports

Advanced Bill of material and shipping bill generation from model

Material and Bolt Lists

Detailed bolt summaries and material lists for easy procurement.

PDF, DXF and DWG files

Issuing drawing files in multiple formats for easier viewing and AutoCAD compatibility

3D IFC Model

Issue 3D file of the model for easier visualization and Bluebeam compatibility

Customized drawings templates

Customized drawing templates with company logos, address and responsible parties section

Takeoffs for Estimation

Initial takeoffs before detailing using Bluebeam RevU


0+

0+

0+

0%

Projects

Commercial Building

400+ tons of steel

Residential Building

5 floor apartment building with steel and glulam beams

Residential Building

5 floor apartment building with complex staircase

Contact us

  • Level 23, 1 Bank of Ceylon Mawatha, Colombo, Sri Lanka
